项目目录

实现代码

初始化

  1. src/index.js

    import '../css/main.css'
import MyCharts from './charts'

new MyCharts({
  select: '#box1',
  ratio: 1.5,
  type: 'cirque'
})

  2. src/charts.js

    import utils from './utils'

class MyCharts {
  constructor(defaultParam) {
    this.defaultParam = defaultParam
    // 获取容器
    this._canvasParDom = document.querySelector(this.defaultParam.select)
    // 容器宽高
    this.containerWidth = this._canvasParDom.clientWidth
    this.containerHeight = this._canvasParDom.clientHeight
    // 创建标签
    this._canvas = document.createElement('canvas')

    // 设置默认配置
    this.defaultConfig = {
      styles: {
        borderColor: "#6b9bb8",
        lineColor: '#9ec8da',
        pointColor: '#41627c'
      },
      data: [],
      x: 40,
      padding: 20,
      fontSize: '16px',
      wd: this.containerWidth * this.defaultParam.ratio,
      ht: this.containerHeight * this.defaultParam.ratio,
      lineWidth: 2,
      hisColor: ['#7b8c7c', '#5c968a', '#576d93', '#a0d878', '#337d56', '#c1d0ae', '#93b469', '#bda29a']
    }

    // 绘制环境 上下文
    this.ctx = this._canvas.getContext('2d')
    // 缩放画布大小（高清处理）
    this._canvas.width = this.containerWidth * this.defaultParam.ratio
    this._canvas.height = this.containerHeight * this.defaultParam.ratio
    // 添加至div 当中
    this._canvasParDom.appendChild(this._canvas)
    // 扩展或者覆盖配置
    this.defaultParam = utils.extendsObj(this.defaultConfig, this.defaultParam)
    // 设置合适的画布宽度
    this.defaultParam.wid = this._canvas.width - 20
    // 设置缩放比
    this.defaultParam.maxPoint = utils.maxData(this.defaultParam.data) / 0.8

    this.init()
  }
  init() {
    switch (this.defaultParam.type) {
      case 'cirque':
        console.log('绘制圆环')
        break
    default:
        console.log('无此功能的绘制')
    }
  }
}
export default MyCharts

动画函数

  1. src/myAnimation.js

    export default function myAnimation(param) {
  let current = 0
  let looped
  // 获取上下文
  const ctx = this.ctx
  // 获取画布
  const _canvas = this._canvas
  // 渲染函数
  const callback = param.render
  // 成功回调
  const successCb = param.success;

  (function looping() {
    looped = requestAnimationFrame(looping)
    if (current < param.percent) {
      // 清空画布
      ctx.clearRect(0, 0, _canvas.width, _canvas.height)
      // 改变current的值，动画时间的变化
      current = current + 4 > param.percent ? param.percent : current + 4
      // 执行渲染函数
      callback(current)
    } else {
      window.cancelAnimationFrame(looping)
      looped = null
      successCb && successCb()
    }
  })()
}

绘制圆环

  1. charts.js

    import utils from './utils'
import Cirque from './cirque'
import myAnimation from './myAnimation'

class MyCharts {
  constructor(defaultParam) {
    this.defaultParam = defaultParam

    // 获取容器
    this._canvasParDom = document.querySelector(this.defaultParam.select)
    // 容器宽高
    this.containerWidth = this._canvasParDom.clientWidth
    this.containerHeight = this._canvasParDom.clientHeight
    // 创建标签
    this._canvas = document.createElement('canvas')
    // 设置默认配置
    this.defaultConfig = {
      styles: {
        borderColor: "#6b9bb8",
        lineColor: '#9ec8da',
        pointColor: '#41627c'
      },
      data: [],
      x: 40,
      padding: 20,
      fontSize: '16px',
      wd: this.containerWidth * this.defaultParam.ratio,
      ht: this.containerHeight * this.defaultParam.ratio,
      lineWidth: 2,
      hisColor: ['#7b8c7c', '#5c968a', '#576d93', '#a0d878', '#337d56', '#c1d0ae', '#93b469', '#bda29a']
    }
    // 绘制环境 上下文
    this.ctx = this._canvas.getContext('2d')
    // 缩放画布大小（高清处理）
    this._canvas.width = this.containerWidth * this.defaultParam.ratio
    this._canvas.height = this.containerHeight * this.defaultParam.ratio
    // 添加至div 当中
    this._canvasParDom.appendChild(this._canvas)
    // 扩展或者覆盖配置
    this.defaultParam = utils.extendsObj(this.defaultConfig, this.defaultParam)
    // 设置合适的画布宽度
    this.defaultParam.wid = this._canvas.width - 20
    // 设置缩放比
    this.defaultParam.maxPoint = utils.maxData(this.defaultParam.data) / 0.8
    this.init()
  }
  init() {
    switch (this.defaultParam.type) {
      // 绘制圆环
      case 'cirque':
        let circleConfig = {
          // 设置圆心坐标
          x: this.defaultParam.wd / 2,
          y: this.defaultParam.ht / 2,
          // 设置半径
          radius: 200,
          // 开始角度
          startAngle: 0,
          // 结束角度
          endAngle: 2 * Math.PI,
          // 所有圆环线的宽度
          arcWidth: 30,
          // 进度圆环停止位置
          target: 90
        }
        // 设置圆环默认配置
        this.circleConfig = utils.extendsObj(this.defaultConfig, circleConfig)
        myAnimation.call(this, {
          // 动画时长
          percent: this.circleConfig.target,
          render: (current) => {
            // current 为动画系数比
            Cirque.call(this, current / 100)
          }
        })
        break
      case 'line':
        break;
      case 'histogram':
        break
      default:
        console.log('无此功能的绘制')
    }
  }
}
export default MyCharts

  2. src/cirque.js

    let Cirque = function (percent) {
  const ctx = this.ctx
  const circleConfig = this.defaultParam

  // 绘制打底圆环
  ctx.beginPath()
  ctx.lineWidth = circleConfig.arcWidth
  // 放射性渐变 第一个圆环的坐标和半径，第二个圆环的坐标和半径
  let grd = ctx.createRadialGradient(circleConfig.x, circleConfig.y, circleConfig.radius - 10, circleConfig.x, circleConfig.y, circleConfig.radius + 10)
  // 渐变颜色
  grd.addColorStop(0, "#e9eae9")
  grd.addColorStop("0.8", "#fefefe")
  grd.addColorStop("1", "#e9eae9")
  // 绘制样式
  ctx.strokeStyle = grd
  // 绘制圆环 圆心坐标、半径、开始角度、结束角度、默认为顺时针
  ctx.arc(circleConfig.x, circleConfig.y, circleConfig.radius, circleConfig.startAngle, circleConfig.endAngle)
  ctx.stroke()
  ctx.closePath()


  // 绘制进度圆环
  ctx.beginPath()
  ctx.lineWidth = circleConfig.arcWidth
  // 放射性渐变 第一个圆环的坐标和半径，第二个圆环的坐标和半径
  let linear = ctx.createLinearGradient(220, 220, 380, 200)
  linear.addColorStop(0, '#ffc26b')
  linear.addColorStop(0.5, '#ff9a5f')
  linear.addColorStop(1, '#ff8157')
  // 绘制样式
  ctx.strokeStyle = linear
  // 绘制圆环 圆心坐标、半径、开始角度、结束角度、默认为顺时针
  ctx.arc(circleConfig.x, circleConfig.y, circleConfig.radius, circleConfig.startAngle, circleConfig.endAngle * percent)
  ctx.stroke()
  ctx.closePath()


  // 起点的圆形
  ctx.beginPath()
  ctx.fillStyle = '#ff7854'
  // 绘制圆环 圆心坐标、半径、开始角度、结束角度、默认为顺时针
  ctx.arc(circleConfig.x + circleConfig.radius, circleConfig.y - 1, circleConfig.arcWidth / 2, circleConfig.startAngle, circleConfig.endAngle)
  ctx.fill()
  ctx.closePath()


  // 终点的圆形
  ctx.beginPath()
  ctx.lineWidth = circleConfig.arcWidth - 10
  ctx.fillStyle = '#fff'
  ctx.strokeStyle = '#ff7854'
  // 转动后的 x 坐标
  let tarX = circleConfig.x + circleConfig.radius * Math.cos(2 * Math.PI * percent)
  // 转动后的 y 坐标
  let tarY = circleConfig.y + circleConfig.radius * Math.sin(2 * Math.PI * percent)
  // 绘制圆环 圆心坐标、半径、开始角度、结束角度、默认为顺时针
  ctx.arc(tarX, tarY, circleConfig.arcWidth - 8, circleConfig.startAngle, circleConfig.endAngle)
  // 圆环填充
  ctx.fill()
  // 圆环描边
  ctx.stroke()
  ctx.closePath()
}
export default Cirque

  3. 终点圆环的位置变化 x，y 坐标的计算

  4. 效果展示

绘制折线图

  1. src/charts.js

    import utils from './utils'
import Cirque from './cirque'
import myAnimation from './myAnimation'
import { drawAxis, drawPoint, drawBrokenLine, drawDashLine } from './broken'

class MyCharts {
  constructor(defaultParam) {
    this.defaultParam = defaultParam
    // 获取容器
    this._canvasParDom = document.querySelector(this.defaultParam.select)
    // 容器宽高
    this.containerWidth = this._canvasParDom.clientWidth
    this.containerHeight = this._canvasParDom.clientHeight
    // 创建标签
    this._canvas = document.createElement('canvas')
    // 设置默认配置
    this.defaultConfig = {
      styles: {
        borderColor: "#6b9bb8",
        lineColor: '#9ec8da',
        pointColor: '#41627c'
      },
      data: [],
      x: 40,
      padding: 20,
      fontSize: '16px',
      wd: this.containerWidth * this.defaultParam.ratio,
      ht: this.containerHeight * this.defaultParam.ratio,
      lineWidth: 2,
      hisColor: ['#7b8c7c', '#5c968a', '#576d93', '#a0d878', '#337d56', '#c1d0ae', '#93b469', '#bda29a']
    }
    // 绘制环境 上下文
    this.ctx = this._canvas.getContext('2d')
    // 缩放画布大小（高清处理）
    this._canvas.width = this.containerWidth * this.defaultParam.ratio
    this._canvas.height = this.containerHeight * this.defaultParam.ratio
    // 添加至div 当中
    this._canvasParDom.appendChild(this._canvas)
    // 扩展或者覆盖配置
    this.defaultParam = utils.extendsObj(this.defaultConfig, this.defaultParam)
    // 设置合适的画布宽度
    this.defaultParam.wid = this._canvas.width - 20
    // 设置缩放比 （折现图数据：数值较小的时候展示不友好）
    this.defaultParam.maxPoint = utils.maxData(this.defaultParam.data) / 0.8
    this.init()
  }
  init() {
    switch (this.defaultParam.type) {
      // 绘制圆环
      case 'cirque':
        let circleConfig = {
          // 设置圆心坐标
          x: this.defaultParam.wd / 2,
          y: this.defaultParam.ht / 2,
          // 设置半径
          radius: 200,
          // 开始角度 0
          startAngle: 0,
          // 结束角度 360
          endAngle: 2 * Math.PI,
          // 所有圆环线的宽度
          arcWidth: 30,
          // 进度圆环停止位置
          target: 90
        }
        // 设置圆环默认配置
        this.circleConfig = utils.extendsObj(this.defaultConfig, circleConfig)
        myAnimation.call(this, {
          // 动画时长
          percent: this.circleConfig.target,
          render: (current) => {
            // current 为动画系数比
            Cirque.call(this, current / 100)
          }
        })
        break
      case 'line':
        myAnimation.call(this, {
          // 动画时长
          percent: 200,
          render: (current) => {
            // 绘制坐标系
            drawAxis.call(this)
            // 绘制数据之间的虚线
            drawBrokenLine.call(this, current / 200)
            // 绘制数据 Y 轴虚线
            drawDashLine.call(this, current / 200)
            // 绘制数据 （数据圆点）
            drawPoint.call(this, current / 200)
          }
        })
        break;
      case 'histogram':
        break
      default:
        console.log('无此功能的绘制')
    }
  }
}
export default MyCharts

  2. src/broken.js

    // 绘制坐标系
export function drawAxis() {
  const defaultParam = this.defaultParam
  const ctx = this.ctx
  const pad = defaultParam.padding
  const bottomPad = 30
  const wd = defaultParam.wd
  const ht = defaultParam.ht
  const data = defaultParam.data
  // 绘制 x、y 轴
  ctx.save()
  ctx.beginPath()
  ctx.lineWidth = 2
  ctx.strokeStyle = defaultParam.styles.borderColor
  ctx.moveTo(pad, pad)
  ctx.lineTo(pad, ht - bottomPad)
  ctx.lineTo(wd - pad, ht - bottomPad)
  ctx.stroke()
  ctx.closePath()

  // 绘制文字刻度
  for (let i = 0; i < data.length; i++) {
    ctx.beginPath()
    ctx.fillStyle = '#333'
    ctx.textAlign = 'center'
    ctx.font = defaultParam.fontSize + ' Microsoft YaHei'
    ctx.fillText(data[i].xVal, i * (defaultParam.wid / data.length - 1) + defaultParam.x, ht - 10)
    ctx.closePath()
  }
  ctx.restore()
}

// 绘制数据
export function drawPoint(speed) {
  const defaultParam = this.defaultParam
  const ctx = this.ctx
  const data = defaultParam.data
  const len = data.length
  const ht = defaultParam.ht
  // 计算
  ctx.save()
  ctx.lineWidth = 2
  for (let i = 0; i < len; i++) {
    let yVal = parseInt(data[i].yVal * speed)
    let tranY = ht - ht * yVal / defaultParam.maxPoint - 30
    let tranX = i * (defaultParam.wid / len - 1) + defaultParam.x
    // 绘制图形
    ctx.beginPath()
    ctx.shadowOffsetX = 0
    ctx.shadowOffsetY = 0
    ctx.shadowBlur = 5
    ctx.shadowColor = defaultParam.styles.pointColor
    ctx.fillStyle = defaultParam.styles.pointColor
    ctx.strokeStyle = '#fff'
    ctx.arc(tranX, tranY, 15, 0, 2 * Math.PI, false)
    ctx.fill()
    ctx.stroke()
    ctx.closePath()
    // 绘制圆形对应的数值
    ctx.beginPath()
    ctx.shadowBlur = 0
    ctx.fillStyle = '#333'
    ctx.textAlign = 'center'
    ctx.font = defaultParam.fontSize + ' MicroSoft YaHei'
    ctx.fillText(yVal, tranX, tranY - 20)
    ctx.closePath()
  }
  ctx.restore()
}

// 绘制数据之间的虚线
export function drawBrokenLine(speed) {
  const defaultParam = this.defaultParam
  const ctx = this.ctx
  const bottomPad = 30
  const data = defaultParam.data
  const ht = defaultParam.ht
  const maxPoint = defaultParam.maxPoint
  const len = data.length - 1
  const stepDots = Math.floor(speed * len)
  // 绘制线条
  ctx.save()
  ctx.beginPath()
  ctx.setLineDash([4, 4])
  ctx.lineWidth = defaultParam.lineWidth
  ctx.strokeStyle = defaultParam.styles.lineColor
  for (let i = 0; i < len; i++) {
    // 起点
    const yVal = data[i].yVal
    const axisY = ht - ht * (yVal / maxPoint) - bottomPad
    const averageNum = defaultParam.wid / data.length - 1
    const axisX = i * averageNum + defaultParam.x
    // 终点
    let axisEndX = (i + 1) * averageNum + defaultParam.x
    let axisEndY = ht - ht * (data[i + 1].yVal) / maxPoint - bottomPad
    // 分段绘制
    if (i <= stepDots) {
      if (i === stepDots) {
        axisEndX = (axisEndX - axisX) * speed + axisX
        axisEndY = (axisEndY - axisY) * speed + axisY
      }
      ctx.moveTo(axisX, axisY)
      ctx.lineTo(axisEndX, axisEndY)
    }
  }
  ctx.stroke()
  ctx.closePath()
  ctx.restore()
}

// 绘制数据 Y 轴虚线
export function drawDashLine(speed) {
  const defaultParam = this.defaultParam
  const ctx = this.ctx
  const bottomPad = 30
  const data = defaultParam.data
  const ht = defaultParam.ht
  const maxPoint = defaultParam.maxPoint
  const len = data.length
  ctx.save()
  for (let i = 0; i < len; i++) {
    // 起始点
    const averageNum = defaultParam.wid / data.length - 1
    let axisX = i * averageNum + defaultParam.x
    let axisY = ht - ht * (data[i].yVal) / maxPoint * speed - bottomPad
    // 开始绘制
    ctx.beginPath()
    ctx.lineWidth = 2
    ctx.setLineDash([4, 4])
    ctx.strokeStyle = '#d6d6d6'
    ctx.moveTo(axisX, ht - bottomPad)
    ctx.lineTo(axisX, axisY)
    ctx.stroke()
    ctx.closePath()
  }
  ctx.restore()
}

  3. 效果展示

绘制直方图

  1. src/charts.js

    import utils from './utils'
import Cirque from './cirque'
import myAnimation from './myAnimation'
import { drawHistogram } from './histogram'
import { drawAxis, drawPoint, drawBrokenLine, drawDashLine } from './broken'

class MyCharts {
  constructor(defaultParam) {
    this.defaultParam = defaultParam
    // 获取容器
    this._canvasParDom = document.querySelector(this.defaultParam.select)
    // 容器宽高
    this.containerWidth = this._canvasParDom.clientWidth
    this.containerHeight = this._canvasParDom.clientHeight
    // 创建标签
    this._canvas = document.createElement('canvas')
    // 设置默认配置
    this.defaultConfig = {
      styles: {
        borderColor: "#6b9bb8",
        lineColor: '#9ec8da',
        pointColor: '#41627c'
      },
      data: [],
      x: 40,
      padding: 20,
      fontSize: '16px',
      wd: this.containerWidth * this.defaultParam.ratio,
      ht: this.containerHeight * this.defaultParam.ratio,
      lineWidth: 2,
      hisColor: ['#7b8c7c', '#5c968a', '#576d93', '#a0d878', '#337d56', '#c1d0ae', '#93b469', '#bda29a']
    }
    // 绘制环境 上下文
    this.ctx = this._canvas.getContext('2d')
    // 缩放画布大小（高清处理）
    this._canvas.width = this.containerWidth * this.defaultParam.ratio
    this._canvas.height = this.containerHeight * this.defaultParam.ratio
    // 添加至div 当中
    this._canvasParDom.appendChild(this._canvas)
    // 扩展或者覆盖配置
    this.defaultParam = utils.extendsObj(this.defaultConfig, this.defaultParam)
    // 设置合适的画布宽度
    this.defaultParam.wid = this._canvas.width - 20
    // 设置缩放比 （折现图数据：数值较小的时候展示不友好）
    this.defaultParam.maxPoint = utils.maxData(this.defaultParam.data) / 0.8
    this.init()
  }
  init() {
    switch (this.defaultParam.type) {
      // 绘制圆环
      case 'cirque':
        let circleConfig = {
          // 设置圆心坐标
          x: this.defaultParam.wd / 2,
          y: this.defaultParam.ht / 2,
          // 设置半径
          radius: 200,
          // 开始角度 0
          startAngle: 0,
          // 结束角度 360
          endAngle: 2 * Math.PI,
          // 所有圆环线的宽度
          arcWidth: 30,
          // 进度圆环停止位置
          target: 90
        }
        // 设置圆环默认配置
        this.circleConfig = utils.extendsObj(this.defaultConfig, circleConfig)
        myAnimation.call(this, {
          // 动画时长
          percent: this.circleConfig.target,
          render: (current) => {
            // current 为动画系数比
            Cirque.call(this, current / 100)
          }
        })
        break
      case 'line':
        myAnimation.call(this, {
          // 动画时长
          percent: 200,
          render: (current) => {
            // 绘制坐标系
            drawAxis.call(this)
            // 绘制数据之间的虚线
            drawBrokenLine.call(this, current / 200)
            // 绘制数据 Y 轴虚线
            drawDashLine.call(this, current / 200)
            // 绘制数据 （数据圆点）
            drawPoint.call(this, current / 200)
          }
        })
        break;
      case 'histogram':
        myAnimation.call(this, {
          percent: 100,
          render: (current) => {
            // 绘制坐标系
            drawAxis.call(this)
            // 绘制直方图
            drawHistogram.call(this, current / 100)
          }
        })
        break
      default:
        console.log('无此功能的绘制')
    }
  }
}
export default MyCharts

  2. src/histogram.js

    // 绘制直方图
export function drawHistogram(speed) {
  const defaultParam = this.defaultParam
  const ctx = this.ctx
  const bottomPad = 30
  const data = defaultParam.data
  const ht = defaultParam.ht
  const maxPoint = defaultParam.maxPoint
  const len = data.length
  let rectHeight = this._canvas.height - bottomPad

  for (let i = 0; i < len; i++) {
    let yVal = data[i].yVal * speed
    let axisY = ht - ht * (yVal / maxPoint) - bottomPad
    const averageNum = defaultParam.wid / data.length - 1
    let axisX = i * averageNum + defaultParam.x

    ctx.save()
    ctx.beginPath()
    ctx.fillStyle = defaultParam.hisColor[i]
    // x, y, width, height
    ctx.fillRect(axisX - 15, axisY, 40, rectHeight - axisY)
    ctx.restore()
  }
}

  3. 效果展示

代码附件下载

打赏作者
您的打赏是我前进的动力
微信
支付宝
评论

中午好👏🏻，我是 ✍🏻   疯狂 codding 中...

粽子

这有关于前端开发的技术文档和你分享。

相信你可以在这里找到对你有用的知识和教程。

了解更多

目录

  1. 1. 项目目录
  2. 2. 实现代码
    1. 2.1. 初始化
    2. 2.2. 动画函数
    3. 2.3. 绘制圆环
    4. 2.4. 绘制折线图
    5. 2.5. 绘制直方图
  3. 3. 代码附件下载
